Factory Tour 1st Stop - Assorted Processing
The complete equipment is a demonstration of professional processing.
Fiber Laser Cutting Machine
This fiber laser cutting machine is suitable for cutting sheet metals such as steel, iron, stainless steel, aluminum, galvanized sheet, carbon steel, silicon steel, brass, copper, and other metal sheets along with round, square, rectangle, and different shapes of the tube.
5-Axis Folding Bed Machine
3D product display shortens operation time and provides a more accurate bending angle of finished products.
Processing Range Specifications:
Plate Dimensions:
3000x1500 mm
0.5~12 mm carbon steel plate
0.5~8 mm stainless steel plate
0.5~5 mm aluminum
Tube Dimensions:
6000x150 mm
Square nozzle: 10x10~100x100 mm
Round tube: Φ10~Φ150 mm
Wall Thickness Array:
0.5~5 mm carbon steel pipe
0.5~5 mm stainless steel tube
0.5~3mm aluminum tube
Single Crank Precision Presses
It can be used in sheet metal production processes like drawing, bending, marking, flattening, and trimming.
We can produce a sheet size maximum of 1250x760mm. (49.21 x 29.92 inches)
Presses Machine
It can be used in sheet and tube metal processes like drawing, bending, marking, flattening, and trimming.
Milling Machine
It can quickly mill flat and curved surfaces and accurately process more complex characters, suitable for metal and plastic materials.
Automatic Punching Machine
A semi-automatic punching machine can change die quickly to increase production efficiency.
Moreover, it rotates 360 degrees to punch metal.
Tube Cutting Machine
The metal tube machine can cut different shapes of tubes according to the length we want and is also suitable for a small number of samples.
Angled-Cutting Machine
Accurate 90° angled- cutting is suitable for the small number of samples.
Processing Capacity Framework:
Cutting capacity: 0.8~4.0 mm
Maximum cutting area: 220x220 mm
Automatic Wire Bending Machine
φ3mm~10mm wire can be bent and formed at multiple angles.
Using rounded tip cutting on the front end to prevent cuts.
Processing Capacity Framework:
Wire diameter range: 2.5~5 m/m
Length range: 40~2500 m/m
Factory Tour 2nd Stop - Welding
To make every single part into a connected piece by welding processing.
Robotic Welding Machine
A robotic welding machine can control consistency and increase production speed.
We set up three working stations that can perform three kinds of welding work simultaneously.
Automatic XY Axis Welding Machine
XY axis welding machine can do multi-axis welding simultaneously, and its high-efficiency automation is suitable for grid and mesh forming.
Processing Capacity Structural Data:
Welding ability: 1. Plate thickness: 1.2+1.2mm | 2. Wire diameter: Φ4.0+Φ4.0mm
Welding desktop matrix: 3M x 3.7M (118.11 x 145.67 inches)
Spot Welding Machine
The spot welding machine has a high production rate, applied to different metals to join.
Spot welding is a low-cost process. There is possible to weld multiple metals at a time.
CO2/TIG Welding by Professional Technicians
CO2 welding by Qiao Song professional technicians.
To do technical welding processing for the position and to be strengthened.
Factory Tour 3rd Stop - Surface Treatment
Grinding
We have two kinds of metal grinding tools, manual and machine, which use to finish off rough edges, deburr metal parts, and smooth welds.
Polish
Metal polishing is a method that uses an abrasive material to smooth surfaces. It becomes more reflective and shiny, enhancing the workpieces' appearance.
Brush Finished
Brushed metal is a surface processed with a dull and shiny procedure, those made through friction.
Our technicians polish the metal with a fine bristle brush on a belt that moves in the same direction the whole time, then softens with a greaseless compound or a medium non-woven abrasive belt.
Electrostatic Powder Coating
Electrostatic powder coating is the technique of applying electrostatic dry paint to a part.
Then, placed in the oven at 200 degrees Celsius, the powder particles melt and coalesce to adhere to the part as a film. The benefit of powder paint is adequate coverage of the part.
Liquid Coating
Liquid coating is wet painted by heat. Then, please place it in the oven at 120~150 degrees Celsius.
Professional engineers formulate the liquid coating using solvents and other additives to give the thickness and finish needed.
Electroplating
Electroplating is the process of coating one metal on another metal surface using electrical energy.
Anodize
Anodizing is an electrochemical process in which electrolytic passivation occurs. This method is essential in increasing the thickness of the natural oxide layer on the surface of the metal parts.
Silk Screen Printing
Silk Screen printing is to transfer ink onto metal by using a mesh with a blocking stencil used in areas made impermeable to the ink.
Digital UV Printing
UV printing is a form of digital printing that can widely use for most flat-substrate plastic, metal, or wood products.
Laser Engraving
Laser engraving produces a permanent finish using a laser beam to etch a logo into a metal product, replicating the logo with precise accuracy. The laser burns off the top layer of the product and reveals the layer beneath.
Thermal vacuum transfer printing
Thermal vacuum transfer printing is a kind of technology that prints the pattern of the ink layer onto the finished material by heating and pressing through a 200-degree Celsius oven.
Heat transfer printing equipment can decorate aluminum-shaped materials and various metal plates with the effect of woodwork or marble finish.
